Stick Trainer 2408

Post by didin »

Minggu-minggu menjelang lebaran, orang-orang pada sibuk mudik, saya malah bengong di rumah...
Nah...daripada suntuk, bongkar-bongkar gudanglah dan nemu:
- empat lembar balsa (ukuran 2mm 1 lbr, ukuran 1.5mm 2 lbr dan ukuran 4mm 1 lembar)
- ESC TP 18A
- Brushless TP 2408
- empat servo mini
- Folding prop 7x6
- satu batang tube (pipa) ex WD

Lalu kepikiran mau buat Guppy mini....(glider), kesulitan bikin desain sayap dan tail section

Akhirnya nekat aja bikin, potong-potong balsa buat rib dulu...
Last edited by didin on 08 Sep 2010, 00:32, edited 2 times in total.
Top
User avatar
didin
Major
Major
Posts: 1793
Joined: 27 Aug 2008, 11:01
Location: Pekanbaru

Re: Nama Sementara: Trainer 2408

Post by didin »

Wing
Panjang 165 cm
Chord 19 cm

Lalu rib tadi disusun-susun seperti ini...

Last edited by didin on 09 Sep 2010, 08:05, edited 2 times in total.
Top
User avatar
didin
Major
Major
Posts: 1793
Joined: 27 Aug 2008, 11:01
Location: Pekanbaru

Re: Nama Sementara: Trainer 2408

Post by didin »

Menggunakan lem CA...ditempat saya malah dikenal dengan lem setan (moga nggak kesetanan dech... [-o< [-o< [-o< )
Jadinya begini...

Top
User avatar
didin
Major
Major
Posts: 1793
Joined: 27 Aug 2008, 11:01
Location: Pekanbaru

Re: Nama Sementara: Trainer 2408

Post by didin »

Hancur dah...bentuk sayap Guppy nggak nemu, malah yang dapat sayap Trainer :( :( :(
...............................
...............................
...............................
...............................
Proyek dilanjut apa nggak ya....?
Top
User avatar
limsiahiang
Senior Airman
Senior Airman
Posts: 111
Joined: 17 Oct 2007, 11:48
Location: kisaran
Contact:
Contact limsiahiang

Re: Nama Sementara: Trainer 2408

Post by limsiahiang »

mantap om didin ...... ditunggu lanjutannya ...
om ..... beli balsa dimana ? kepingin juga buat yg balsa .
thank's

salam.
Top
User avatar
didin
Major
Major
Posts: 1793
Joined: 27 Aug 2008, 11:01
Location: Pekanbaru

Re: Nama Sementara: Trainer 2408

Post by didin »

Balsa saya beli dari Jawa Om...di Pekanbaru nggak ada.

PM Sent...
Top
User avatar
ciptaS
Staff Sergeant
Staff Sergeant
Posts: 292
Joined: 05 Apr 2009, 00:42
Location: Rt. Prapat pekan baru
Contact:
Contact ciptaS

Re: Nama Sementara: Trainer 2408

Post by ciptaS »

didin wrote:Hancur dah...bentuk sayap Guppy nggak nemu, malah yang dapat sayap Trainer :( :( :(
...............................
...............................
...............................
...............................
Proyek dilanjut apa nggak ya....?


lanjut terus pak,,, tar klu kurang kayunya saya kirim lagi kayu ala pujud....... pasti siip.... menikmatinya sambil berfikir design yang akan di buat,,, :lol: :lol: :lol: :lol: :lol: :lol: :lol: :lol: :lol:
Top
User avatar
didin
Major
Major
Posts: 1793
Joined: 27 Aug 2008, 11:01
Location: Pekanbaru

Re: Nama Sementara: Trainer 2408

Post by didin »

ciptaS wrote:lanjut terus pak,,, tar klu kurang kayunya saya kirim lagi kayu ala pujud....... pasti siip.... menikmatinya sambil berfikir design yang akan di buat,,, :lol: :lol: :lol: :lol: :lol: :lol: :lol: :lol: :lol:


Baik Pak Cip...nanti kalau balsanya kurang...tak pesan ke Pujud :lol: :lol: :lol:
Top
User avatar
didin
Major
Major
Posts: 1793
Joined: 27 Aug 2008, 11:01
Location: Pekanbaru

Re: Nama Sementara: Trainer 2408

Post by didin »

Fuselage
Panjang fuselage 95cm...
sebagian balsa 4mm dan disambung dgn batang tube ex WD...
Bentuknya masih berusaha keras menyerupai bentuk Guppy.... :lol: :lol: :lol:


Last edited by didin on 09 Sep 2010, 08:05, edited 1 time in total.
Top
User avatar
didin
Major
Major
Posts: 1793
Joined: 27 Aug 2008, 11:01
Location: Pekanbaru

Re: Nama Sementara: Trainer 2408

Post by didin »

Ini bagian sambungan dgn tube ex WD...

Dan ini dudukan motor TP 2408...
